CMAX2 Frame Rail Pair

CMAX2 Frame Rail Pair Image
Detail Image
Detail Image
Detail Image

Fully machined from solid billet aluminum bars, this 4.75mm thick chassis rail pair is the bones for CMAX2. It's thick in the middle, rigid designed, and fool proof for assembly. The precision pockets on the chassis support the items between the rails, and keep it square and solid when assembled. Many of the holes are threaded already to make assembly a breeze when using GCM mount sets and inner fenders. M3 threaded holes are roll formed instead of cut for a much stronger thread on the sides. M2 top holes are also roll formed, and are used for 2 different servo mount positions and transfer case mounts.
The profile of this chassis fits in the 'under 2 inch rise' specification for Class 1 SORRCA rules, as well as bolt on shock tower and mounts required for the class spec.
Black anodize finish all around. The full chassis length is 500mm, 19.7 inches end to end.

Includes 1x Left rail and 1x Right rail.

Your Price:C$55.00
